It is a polyester polyurethane resin-based, two-component and color flooring with high content of solids and low viscosity, whic is used as topcoat with textured – orange peel appearance fort he paint systems designed as multilayer or thin flooring
• On the concrete, cement or epoxy mortars for all industrial floors:
• For the units of warehouses, hangars and repair-maintenance and assembly with forklift, loader and heavy vehicle traffic:
• For epoxy multilayer systems applicable at the factories,
workshops, production and packaging sites; and
• For floors subject to medium to heavy load and in much more places where mechanical strength and wear resistance is required.
• Applicable with airless spray paint application equipment;
• Resistant to diesel, petrol and many chemicals;
• Homogenous, aesthetical and orange peel appearance,
• Resilient hard structure and high wear resistance.
Finish | : Semi Glossy |
Color | : Any color |
Density | : 1,30 ± 0,05 kg/It (A+B) |
Mixing ratio | : 2:1 (A:B – by weight) |
Solid by Volume | : %75 (A+B) |
Pot life (+10°C) | : 120 minutes |
(+30°C) | : 50 minutes |
Wait Time Between Coats | : 24 hours / 20°C |
Ready for Light Traffic | : 2 days / 20° |
Full Cure | : 7 days / 20°C de |
Taber Abrasion Resistance | : 30mg (in full cure) |
Mixing Procedure: It is a two-component product and it should, therefore, be propared at the mix ratio specified for the quantity to be used, taking into consideration the pot life. For a homogenous mixture, make sure that the product temperature should not be less than 15°C. Component A should be stirred by itself by use of a mechanical mixer quickly and then the hardener (Component B) should be added, taking care of the mix ratio. Components A and B should be stirred by using mechanical mixer for minimum 3 minutes until you have a homogenous mixture. Make sure the prepared mixture is consumed during the pot life of the mixture.
Surface Application: After made ready to apply, the mixture is preferably applied by airless spray or roller in amount specified in the paint system or in such amount to obtain the desired dry film thickness as controlled by wet film comb. If it is desired that the fresh flooring spread over the surface completely should give a thicker orange peel appearance, the paint film is combed by using coral roller 30 – 40 minutes after the application. Wait time between the coats is minimum 24 hours (20°C) and maximum 5 days. It is very important that the second coat should be applied within the time for overcoating above. It reaches to a full mechanical and chemical strength in about 7 days.
Clean Up: Cellulosic or Polyurethane thinner
A 15-kg set of H ELLTECH FLOOR NOVATECH FLOOR PUR consists of Component A in one pail of net 10 kg and Component B in one galloon of net 5 kg.
Store the product in a cool and dry place. Shelf life of the product is 1 year for Components A and B when stored properly in the original container unopened.
Impregnation Primer:
HELLTECH FLOOR / NOVATECH FLOOR EPOXY SEALER 5000 :400-500 gr/m2
(Depending on the concrete surface, it is recommended to thin 30-40% with Epoxy Thinner for better impregnation)
Textured Topcoat :
HELLTECH FLOOR / NOVATECH FLOOR PUR TOPCOAT-1300,
1.coat : 200-300 gr/m2,
2.coat : 200-300 gr/m2
Related products
Company
Parquet Products
Waterproof Products
Contact Information
Head Office Address
Orucreis Mah.Tekstilkent Cad. No: 10V Blok No:214 (2. Kat) Tekstilkent Ticaret Merkezi Esenler / ISTANBUL / TURKEY
Factory Address
Buyukbakkalkoy Mahallesi Yakacik Yolu Sokak No: 2/1 Merkez
Maltepe / ISTANBUL / TURKEY
